Continental Hydraulics – Cetop 3. P03 MSV-RP Pressure Relief Valve, Pilot Operated/Balanced Spool

~ scroll down to find the part you need ~

Continental Hydraulics are at the forefront of engineering hydraulic solutions for over 50 years-a testament to a long-standing reputation built upon your challenges and opportunities. A worldwide leader- a one-stop-shop for valves, pumps, power units and proportional products-all assembled in the USA.

The Continental Hydraulics P03 MSV-RP pilot-operated pressure relief cartridge valve with balanced sliding spool provides accurate, smooth pressure regulation.
The valve blocks flow from port 1 to port 2 until sufficient pressure is present at port 1 to force the pilot poppet from its seat, thus opening the valve.
This cartridge relief valve offers a smooth transition in response to a load change in a hydraulic circuit.

Features and Benefits

  •  Leakproof screw adjustment cannot be backed out of valve.
  •  All external parts are zinc-plated for long life against elements.
  •  All cartridges are 100% tested functionally.
  •  Industry common cavity.

Product Specification

Specifications

  • Flow: 30 GPM (113 L/M) Nominal
  • Internal Leakage: 115cc/min (7 cu. In/min)
  • Valve Bodies: 3000 PSI (207 Bar) = Aluminum (2024-T4)
  • Estimated Shipping Weight: 2 # Aluminum

Continental Hydraulics – P03 MSV-PDR Pressure Reducing / Relieving Valve – Data Sheet

Additional Information

Manufacturer

Continental Hydraulics

Modular Stack Valves

Pressure Control Relief Valves
