Continental Hydraulics VSD0*M – Pilot Operated Directional Control Valve

~ scroll down to find the part you need ~
Continental Hydraulics are at the forefront of engineering hydraulic solutions for over 50 years-a testament to a long-standing reputation built upon your challenges and opportunities. A worldwide leader- a one-stop-shop for valves, pumps, power units and proportional products-all assembled in the USA.

The VSD0*M and VPD*M pilot operated directional control valves are available with either electric solenoid or hydraulic actuation of the main spool.
Available in 5 standard NFPA and ISO patterns, these pilot operated valves are used in applications requiring high flow rates.

The valves are available in both 2 or 3 position and various spool flow patterns.
On VSD0*M valves, the configuration for internal or external pilot/drains can be easily changed in the field.
Also available to improve consistent cycling of the valve are pilot pressure reducing, pilot chocks, and main stage stroke adjustments.

The valves are available in both 2 or 3 position and various spool flow patterns.
On VSD0*M valves, the configuration for internal or external pilot/drains can be easily changed in the field.
Also available to improve consistent cycling of the valve are pilot pressure reducing, pilot chocks, and main
stage stroke adjustments.

Product Specification

Description VSD05M
VSD07M
VSD08M VSD010M
Maximum Operating Pressure P – A -B Ports 4600 psi / 320 bar 5000 psi / 350 bar 5000 psi /350 bar 5000 psi / 350 bar
Maximum Operating Pressure T Port (Ext.Drain) 3600 psi / 250 bar 3600 psi / 250 bar 3000 psi / 210 bar 3000 psi / 210 bar
Maximum Operating Pressure T Port (Int.Drain) 2000 psi / 140 bar 2000 psi / 140 bar 2000 psi /140 bar 2000 psi / 140 bar
Maximum Operating Pressure X Port 3000 psi / 210 bar 4000 psi / 280 bar 5000 psi /350 bar 4000 psi / 280 bar
Minimum Pilot Pressure 72 psi / 5 bar 170 psi / 12 bar 72 psi / 5 bar 170 psi / 12 bar
Max Flow Rate  40 gpm / 150 l/min 80 gpm / 300 l/min  125 gpm / 473 l/min  290 gpm / 1100 l/min
Mounting Surface  NFPA D05 alt. A/alt.B
Iso 4401-05-05-0-05
  NFPA D05 alt. A/alt.B
Iso 4401-05-05-0-05
  NFPA D05 alt. A/alt.B
Iso 4401-05-05-0-05
  NFPA D05 alt. A/alt.B
Iso 4401-05-05-0-05
Weight  19lbs / 8.6 kg  19.4 lbs / 8.8 kg  34 lbs / 15.4 kg  110 lbs / 50 kg

Continental Hydraulics – VSD0*M – Pilot Operated Directional Control Valve Data Sheet

Additional Information

Directional Control Valves

Solenoid Controlled – Pilot Operated

Manufacturer

Continental Hydraulics
