Daikin DV – Single Stage Vane Pump

~ scroll down to find the part you need ~
Market leaders in environmentally responsible heat pumps, ventilation and air conditioning systems for domestic, commercial and industrial applications.

  • Low noise and low pulsation

    Since the cam ring which enables to minimize the displacement variation, the operation sound is quiet and the pulsation is small, resulting in gaining the stable performance.
  • High reliability

    Good pressure balance can be kept due to the structure which maintains complete oil equalization. As a result, a long life is promised because an eccentric load will not be on the shaft and bearing.

Product Specification

Displacement

Model Code 0.4 MPa
{4 kgf/cm²}
3 MPa
{30 kgf/cm²}
5 MPa
{50 kgf/cm²}
7 MPa
{70 kgf/cm²}
 DVS*-1V 6.4 L/min 5.9 L/min 5.4 L/min 5.0 L/min
 DVS*-2V 9.0 L/min 8.4 L/min 8.0 L/min 7.5 L/min
 DVS*-3V 13.5 L/min 12.6 L/min 12.3 L/min 12.0 L/min
 DVS*-4V 19.5 L/min 18.8 L/min 18.4 L/min 18.0 L/min
 DVS*-5V 33.0 L/min 32.2 L/min 31.6 L/min 31.0 L/min
 DVS*-6V 43.0 L/min 42.2 L/min 41.6 L/min 41.0 L/min
 DVM*-1V 57.0 L/min 55.5 L/min 53.8 L/min 52.0 L/min
 DVM*-2V 72.0 L/min 70.0 L/min 68.5 L/min 67.0 L/min
 DVM*-3V 87.0 L/min 85.0 L/min 83.5 L/min 82.0 L/min
 DVM*-4V 108.0 L/min 106.0 L/min 104.5 L/min 103.0 L/min
 DVM*-5V 140.0 L/min 137.0 L/min 135.5 L/min 134.0 L/min
 DVL*-2V 164.0 L/min 157.0 L/min 152.0 L/min 148.0 L/min
 DVL*-3V 207.0 L/min 200.0 L/min 196.0 L/min 192.0 L/min
 DVL*-4V 226.0 L/min 219.0 L/min 216.0 L/min 208.0 L/min



Shaft Power Input

Model Code 0.4 MPa
{4 kgf/cm²}
1 MPa
{10 kgf/cm²}
3 MPa
{30 kgf/cm²}
5 MPa
{50 kgf/cm²}
7 MPa
{70 kgf/cm²}
 DVS*-1V 0.2 kw 0.3 kw 0.7 kw 1.0 kw 1.4 kw
 DVS*-2V 0.2 kw 0.4 kw 0.8 kw 1.3 kw 1.7 kw
 DVS*-3V 0.22 kw 0.5 kw 1.1 kw 1.7 kw 2.4 kw
 DVS*-4V 0.25 kw 0.6 kw 1.4 kw 2.3 kw 3.2 kw
 DVS*-5V 0.33 kw 1.0 kw 2.3 3.6 kw 4.9 kw
 DVS*-6V 0.45 kw 1.3 kw 2.9 kw 4.5 kw 6.2 kw
 DVM*-1V 0.5 kw 1.6 kw 3.8 kw 6.0 kw 8.5 kw
 DVM*-2V 0.8 kw 2.2 kw 4.8 kw 7.7 kw 10.5 kw
 DVM*-3V 1.2 kw 2.7 kw 6.2 kw 9.6 kw 13.0 kw
 DVM*-4V 1.6 kw 3.6 kw 7.8 kw 11.9 kw 16.0 kw
 DVM*-5V 2.1 kw 4.6 kw 9.5 kw 14.3 kw 19.0 kw
 DVL*-2V 3.2 kw 6.2 kw 11.6 kw 17.3 kw 23.0 kw
 DVL*-3V 3.8 kw 7.5 kw 15.0 kw 22.5 kw 28.3 kw
 DVL*-4V 4.8 kw 8.8 kw 16.7 kw 24.8 kw 31.5 kw



Weight

Model Code Flange Connection Type Foot Mounting Type
 DVS * 10 kg 11 kg
 DVM * 26 kg 26 kg
 DVL * 107 kg 110 kg

Daikin – DS – Compact Type Single Stage Vane Pump – Datasheet

Additional Information

Hydraulic Pump Units

Vane Pump

Manufacturer

Daikin
