Continental Hydraulics - Cetop 3. P03 MSV-PD - Pressure Reducing / Relieving Valve

Continental Hydraulics are at the forefront of engineering hydraulic solutions for over 50 years-a testament to a long-standing reputation built upon your challenges and opportunities. A worldwide leader- one-stop-shop for valves, pumps, power units and proportional products-all assembled in the USA.

The Continental Hydraulics P03 MSV-PD pilot-operated hydraulic pressure reducing / relieving valve acts as a pressure-regulating device for a secondary circuit. It features a sliding spool and screw-in cartridge.

Operations

The valve will allow flow from the inlet port to the controlled port until pressure in the controlled port exceeds the force of the spring bias. Then the spool will shift and restrict. This causes reduced pressure in the controlled port. The valve will maintain the same pressure as the force of the spring setting regardless of the pressure at the inlet port. In this mode, the valve will also relieve from the controlled port to the drain port, regulating pressure at the controlled port.

Features and Benefits

•  All external parts are zinc-plated for long life against elements.
•  All cartridges are 100% tested functionally.
•  Industry common cavity.
