Continental Hydraulics PowrFlow™ LPV-17B30-RF-0-2S-A Axial Piston Pump, 36cc/rev

Continental Hydraulics

View all specifications

Continental Hydraulics LPV series of pumps, are variable displacement axial piston pumps with variable swash block, suitable for applications with open loop circuits and intermediate pressures. Available in 5 nominal displacements. These Pressure compensated pumps automatically adjust the output flow rate to maintain the set pressure. The maximum output flow can be limited via maximum volume adjustment screw. SAE J&44 2-Bold Mounting Flange Available with four difference types of control compensator options designed to meet your application or requirements.

Key Features:

External bearing and shaft seal provide easy access for servicing.
Multiple compensator options including: Pressure Compensator, Remote pressure, load sensing and a D03 (CEETOP 03) valve mount permitting pressure control of circuits from dual pressure to Proportional pressure.
Like the proven Continental HPVR piston pump, the swash block and saddle design allows consistent control and prolonged operating life. Saddle bearing can also be easily serviced.
Spherical port plate design provides extremely quiet operation.
Maximum volume adjustment screw fited as standard

Downloads & Datasheets

Continental Hydraulics - LPV Series Product Catlogue

Description	LPV-4	LPV-8	LPV-11	LPV-17	LPV-22
Maximum Displacement	0.488 in³/rev / 8 cc ³/rev	0.976 in³/rev / 16.5 cc ³/rev	1.342 in³/rev / 22 cc ³/rev	2.196 in³/rev / 36 cc ³/rev	2.807 in³/rev / 46 cc ³/rev
Flow at 1800 RPM	3.8 gpm / 14.4 lpm	7.9 gpm / 30 lpm	10.6 gpm / 40 lpm	17.1 gpm / 64.8 lpm	21.9 gpm / 92.8 lpm
Operating Pressure	3000 PSI / 210 Bar	3000 PSI / 210 Bar	3000 PSI / 210 Bar	3000 PSI / 210 Bar	3000 PSI / 210 Bar
Operating Speed	500 min to 2000 max	500 min to 2000 max	500 min to 2000 max	500 min to 2000 max	500 min to 2000 max
Rotation Direction	Clockwise (as viewed from shaft side)	Clockwise (as viewed from shaft side)	Clockwise (as viewed from shaft side)	Clockwise (as viewed from shaft side)	Clockwise (as viewed from shaft side)
Mounting Flange	"A" 2-Bolt	"A" 2-Bolt	"A" 2-Bolt	"B" 2-Bolt	"B" 2-Bolt
Weight	20 lbs/ 9 kg	27 lbs / 12 kg	27 lbs / 12 kg	51 lbs / 23 kg	51 lbs / 23 kg
Ambient Temperature Range	15 to 120 °F / -10 to 50°C	15 to 120 °F / -10 to 50°C	15 to 120 °F / -10 to 50°C	15 to 120 °F / -10 to 50°C	15 to 120 °F / -10 to 50°C
Fluid Temperature Range	15 to 160 °F / -10 to 70°C	15 to 160 °F / -10 to 70°C	15 to 160 °F / -10 to 70°C	15 to 160 °F / -10 to 70°C	15 to 160 °F / -10 to 70°C
Fluid Cleanliness	ISO 18/16/13 is Recommended	ISO 18/16/13 is Recommended	ISO 18/16/13 is Recommended	ISO 18/16/13 is Recommended	ISO 18/16/13 is Recommended
Rec. Operating Viscosities	60 to 140 SUS / 20 to 75 cSt	60 to 140 SUS / 20 to 75 cSt	60 to 140 SUS / 20 to 75 cSt	60 to 140 SUS / 20 to 75 cSt	60 to 140 SUS / 20 to 75 cSt
